Laser Engraving Machine
20W Fiber Laser Engraving Machine | Metal Marking System
₹115,000
Availability
In Stock • Ready to ship
Cash On Delivery
7 Days Return
Secure Pay
Kh. No. 33/6, Ranaji Enclave, Najafgarh New Delhi 110043, Najafgarh, Delhi 110043
This product is sold and fulfilled by Techno Laser Engineering via Vyapari Store platform.
20W fiber laser engraving machine provides permanent, high-contrast marks on metals and hard plastics. Designed with an advanced galvo scanner system, the benchtop unit delivers sharp text, fine serial numbers, and 2D codes without mechanical contact.
| Specification Parameter | Technical Details |
|---|---|
| Product Name | 20W Fiber Laser Engraving Machine |
| Laser Output Power | 20 Watts (Pulsed Fiber) |
| Laser Wavelength | 1064 nm |
| Working / Marking Area | 110 mm x 110 mm (Standard F-theta Lens) |
| Marking Speed | ≤ 7000 mm/s |
| Engraving Depth | ≤ 0.2 mm - 0.5 mm (Material dependent) |
| Minimum Line Width | 0.01 mm |
| Minimum Character Size | 0.15 mm - 0.2 mm |
| Repeatability Accuracy | ± 0.002 mm |
| Beam Quality (M²) | < 1.5 |
| Cooling System | Internal Air Cooling |
| Focus System | Dual Red Dot Pointer Alignment |
| Compatible Materials | Stainless Steel, Aluminum, Brass, Copper, Titanium, Gold, Silver, Hard ABS, PVC |
| Supported Graphic Formats | PLT, DXF, AI, DST, BMP, JPG, JPEG, GIF, TGA, PNG |
| Control Software | EzCad2 / LightBurn Compatible |
| Interface & Connectivity | USB 2.0 / USB 3.0 |
| Operating System Compatibility | Windows 7, 8, 10, 11 (32-bit & 64-bit) |
| Power Supply Requirement | AC 110V / 220V ± 10%, 50/60 Hz |
| Total Power Consumption | ≤ 450 Watts |
| Operating Environment | Temperature: 10°C to 35°C | Humidity: 10% to 90% (Non-condensing) |
| Expected Laser Source Lifespan | Up to 100,000 Hours |
20W fiber laser engraving machine is a compact desktop workstation built for clear, permanent marking. It uses a focused laser beam to etch designs directly onto surfaces without inks, bits, or chemical sprays. Setup is simple: plug the unit into a standard wall outlet, connect the USB cable to a PC, and begin marking parts right away.
Key Features
Air-Cooled Fiber Laser Source: Runs cool without water chillers or external liquid tanks.
High-Speed Galvo Scanner: Moves the beam rapidly for crisp corners and clean line work.
Dual Red Dot Pointer: Makes manual focus adjustment fast, precise, and user-friendly.
Solid Aluminum Base Plate: Features pre-drilled grid holes for clamping fixtures securely.
Foot Pedal Switch: Allows hands-free operation to speed up batch production runs.
Applications
Adding permanent serial numbers, lot codes, and date stamps to industrial parts.
Engraving 2D Data Matrix codes and QR barcodes on metal tags and labels.
Marking company logos onto stainless steel, brass, titanium, and aluminum items.
Etching text and designs on tools, hardware components, and electrical plates.
Personalizing small metal gifts, nameplates, and hard ABS plastic housings.
Technical Benefits
Because it is a non-contact metal marking tool, parts never suffer tool wear, pressure damage, or surface bending. The solid-state laser requires no lamps or alignment mirrors, which minimizes daily upkeep. The machine consumes under 500W of electrical power, helping keep daily shop running costs low.
Industry Usage
Small and mid-sized machine shops, electronics assemblers, automotive component makers, medical tool suppliers, and hardware manufacturers regularly rely on this equipment. It delivers industrial traceability requirements while fitting neatly onto standard shop workbenches.
Performance Advantages
Equipped with an efficient galvo scanner system, the unit finishes marks in seconds rather than minutes. The high beam quality ensures sharp edges even on tiny 1mm characters, while the integrated laser etching device technology keeps output contrast consistent across extended work shifts.
